TIG IT: How a TIG Welder Works and When to TIG Weld

Print Article
Sleepy Gomez discusses the basics of TIG welding in motorsports applications, and the proficiency of a TIG welder like the Syncrowave® 200 on aluminum and chrome-moly.

By Sleepy Gomez, Publisher and Technical Director, Oval Trak Digest.com

First off, let's define the TIG welding process and provide some history. TIG stands for Tungsten Inert Gas and is technically called Gas Tungsten Arc Welding or GTAW. The process uses a non-consumable tungsten electrode that delivers the current to the welding arc. The tungsten and weld puddle are protected and cooled with an inert gas, typically argon. TIG welding is similar to oxy-acetylene welding in that you use a filler material for build-up or reinforcement. TIG welding is often referred to as Heli-arc welding, originating from an early Hobart "Heli-Arc" machine. The name comes from using helium gas as a shield around the electric arc. TIG welding was developed in the 1930s and was used during World War 2 as the preferred way to weld many aircraft parts. Previously, some alloy steels and aluminum had to be welded with a torch, something that required considerable skill and time.

In race car fabrication, we use the TIG welding process for aluminum and 4130 chrome-moly steel. If you are going to be welding on either of these materials, you need a quality TIG welder. Miller offers products that will accommodate anyone from a home hobbyist to an advanced user.

My machine of choice is the Miller Syncrowave 200. This welder has an air-cooled torch rather than a water-cooled setup. Why? Well, it is less expensive, as well as lighter. Unless you are in a production situation where you are running long welds without interruption, the air-cooled torch is quite adequate for this product. Most TIG welders will have an AC/DC switch. Use DC current for welding steels and AC current when welding aluminum. By the way, this welder can also be used for Stick welding.

If you have ever welded with an oxy-acetylene torch, then you can easily weld with a TIG machine. The TIG process uses an electric torch, where you hand feed a filler rod into the molten puddle.

The ability to soft start and soft stop the heat makes the TIG process different from other types of electric welding. Some people like the accelerator pedal to control the heat if they are working on a bench and others like finger tip remotes on the torch if they are working in areas that are considered out of position. The remote adjusts the heat while you are welding.

Before you use a TIG unit, you should be familiar with the parts of the welder and the function of each part. The work lead, often referred to as a ground cable with a clamp, must be attached to the work piece or to the metal surface that the work piece is on. The welding lead cable will have an electric TIG torch on the end. Along with the cable is a small line that carries the argon gas. The inert gas performs like the flux coating on a stick electrode in that it protects the weld from air-borne contaminants. You will need a gas bottle and a regulator. DO NOT use the same gas that you would use with a MIG welder.

The torch disassembles into several parts. The small tungsten rod (several sizes are available) is the electrode. This electrode does not burn up like a filler rod. The tungsten can be sharpened to a point or ball shape depending on what you are welding. A copper collet holds the tungsten and is used to adjust the length that the tungsten protrudes from the cup. The ceramic cup (usually pink) can be unscrewed and replaced as needed. Several cup outlet diameters are available. In the collet body, there are several cross-holes that allow the gas to pass into the cup and surround the tungsten. This excludes oxygen that would contaminate a weld. Loosening the back cap will reduce the collet's grip on the tungsten and allow the tungsten to be removed for sharpening or replacement.

This is the electric torch. It is air-cooled, making it light and easy to handle. Hold the torch in one hand and feed the rod with the other. The tungsten (T) is shielded by the inert (I) gas (G), normally argon. This gas shield is the flux that keeps oxygen from contaminating the weld by oxidizing the metal.

If you have never used a TIG machine, the "throttle" may seem unusual. This is a foot-operated variable amperage control. After the maximum amperage desired is pre-set on the machine, the "throttle" will allow you to vary the amperage up to the maximum pre-set amperage. This is useful when welding alloy steels, such as 4130 chrome-moly. The foot control allows you to slowly initiate the heat, and after the weld is complete you can slowly reduce the heat. This soft start and soft stop prevents temperature shocking the metal. Many alloy steels used in race cars are sensitive to thermal shock. Welding by other means may lead to brittle welds.

The TIG machine itself, and I really like my Miller Syncrowave 200, has numerous controls. There is a main switch in the center that selects negative electrode (torch) for TIG welding steel, AC for welding aluminum and positive electrode for Stick welding using reverse polarity rods.

Across the top are several buttons. On the left, select the TIG or Stick process. One of the most vital controls for welding on aluminum is the balance control, located smack dab in the middle of the controls. The balance controls the cleaning vs. penetration on aluminum. The higher the balance, the more penetration you'll get. Typical settings range from 70 to 80 percent, or 7-8. To the right you can select normal or pulse mode. When using the pulse mode on aluminum, the amperage is automatically varied in a pulse fashion. This can reduce the heat into the work piece and help you achieve a better weld, as well as reduce the heat-affected zone. Further, pulsing automatically produces "stacked dimes" or a rippled wave pattern in the weld. At the far left is a feature I particularly like, an amp control. The machine ranges from 5 to 200 amps. If I set the machine to 45 amps, that's the maximum output the machine will give me. When I'm welding something thin, I can't accidentally apply too much current through the foot pedal. It's like insurance.

These are the internal parts of the electric torch. The collet holder holds the collet on one end and a ceramic cup on the other. The collet holds and clamps the tungsten in position. The holes in the collet holder allow the gas to flow around the tungsten to prevent contamination of the weld.

Now, let's get ready to weld. The TIG process is not unlike welding with an oxy-acetylene torch. You hold the torch in one hand and feed a filler rod with the other. An auto-darkening welding hood makes starting the weld more accurate. For years I welded with a simple dark fixed-shade helmet. It must have taken me 7 or 8 seconds to adapt to the auto-darkening hood.

A common available filler rod for welding aluminum is the 4043 alloy. If you are trying to color match welds on parts to be anodized, use 5356, which will match better than most others. Use a filler material guide to better match the base material to the filler material.

When TIG welding steel, use a filler material, or filler rod, similar to the filler rod used in oxy-acetylene welding. It has a thin copper coating to inhibit rusting. I've been told by welding professionals that the copper coating is not detrimental to the welds even on chrome-moly. However, a non-coated filler rod is available and must be kept rust free.

To start, gather up some clean metal scraps. You should have a metal top table or at least a metal plate clamped firmly to the table. You might find that welding is somewhat like sex. Your position has a lot to do with your enjoyment. Pull up a stool. Place the foot pedal within easy reach once you are seated. It is important to wear the proper protective welding gear, such as a long-sleeved shirt or coveralls, a welding helmet, and leather gloves and shoes, even when TIG welding.

A ceramic cup shrouds the tungsten electrode directing the gas flow. These cups come in several sizes for different welding applications.

Set the welder to the correct polarity, which will be specified by the type of metal you are going to weld-AC for aluminum or DC for steels. Select the appropriate welding rod. Make sure the gas bottle is turned on. I set the regulator at about 20 CFH (cubic feet per hour). Check that the tungsten has the correct point for the metal you are welding. It should be sticking out of the cup by about 1/8 in. Hold the torch up, away from your body, depress and release the foot pedal. You should be able to hear the gas flow. If not then find out why. Did you turn on both the welder and the bottle?

You are ready to weld. Let me explain a few TIG pitfalls to make your learning process easier. The tungsten should never touch the work piece. When it does, you will notice a different sound and color, which means the tungsten is contaminated. Loosen the back cap and slip the tungsten (it is hot) out. Go to the grinder, preferably one with a wheel dedicated to tungsten, and clean the end of the tungsten. Reshape the end as necessary. You will dip the tungsten many times as you learn, but, with more practice you'll be steadier and the less it will happen.

This is the tungsten electrode. It has been ground to a ball shape on one end and a point on the other. Each shape has its application. The tungsten is considered a consumable item and will be used up over time.

Back at the welding table, get some practice. Use different heats and different feeds of the rod on your scraps.

This article won't make you a proficient TIG welder, but it should give you a good understanding of how a TIG welder works and why you might need one. A good machine, such as my Miller Syncrowave 200, has the capacity to weld up to 1/4-in. aluminum and 3/8-in. steel or stainless steel; in fact, it can do more than I ask it to do. The Syncrowave has capabilities that are beyond the reach of this article. It is not difficult to use, but it will take patience to use it properly. If you need to weld aluminum or precision weld steels, this is the way to get it done.

This is a very nice tool if you do a lot of TIG welding. Its a hand-held unit that automatically grinds. tungsten to a point. Just the thing for race-car welders! This is a foot control for the speed (oops!), rather amperage, control of the Miller TIG machine. Though not shown, there is a thumb control available that attaches to the torch that also allows amperage control.
Part of a weld joint has been completed. Too much heat directed to the thin edge has burned a hole in the metal of this .035-in. steel tube. With the foot amperage control, the heat can be controlled enough to repair this flaw. With a bit of practice, this won't happen again. Preparing to start a weld: the torch with the tungsten in place. The welding rod is ready to be added. With an auto-darkening helmet, everything can be positioned without having to shake your head to flip the hood down.
The TIG welder in action. The rod is being fed with one hand while the other guides the torch. A comfortable position here means a lot to weld quality. This is the type of weld joint you should avoid. All these tubes converged at one point and were tack welded into place. It is virtually impossible to reach the inside edges of the tubes. The part should have been welded in sections that were stacked so that the last welds were properly positioned for welding.
Here the welder is using the soft stop technique. He finished the weld and slowly reduced the amperage. The gas flow remains on for a few seconds to prevent weld contamination. This technique is reversed when beginning a weld by slowly bringing the heat up. All of this prevents thermal shock, which you must prevent on chrome-moly steels. A finished weld? No. This joint has been welded as much on the bottom as on the top. It is advantageous to weld a joint from side to side to control warpage. Turn the workpiece as necessary.
At the top of the front panel on Miller's Syncrowave 200 is what I call the wonder panel. Selections of TIG or Stick, adjustment for balance wave and the wonderful pulse. A nice feature is the amperage limiter. A dial sets the LED display at the top. When welding thin metals, this adjustment can be set to prevent an itch on your big toe from overheating the weld. All in all, this is a quality welder, from which you can turn out quality work.
